AV Gear AVG-CS-HDMI44 - 4 X 4 Ultra Compact HDMI Matrix
AV Gear AVG-CS-HDMI44 - 4 X 4 Ultra Compact HDMI Matrix
AV Gear AVG-CS-HDMI44 - 4 X 4 Ultra Compact HDMI Matrix
AV Gear AVG-CS-HDMI44 - 4 X 4 Ultra Compact HDMI Matrix

AV Gear AVG-CS-HDMI44 - 4 X 4 Ultra Compact HDMI Matrix

Brand: AV Gear

$590.00
/
10 interest free payments from $59.00 with

AV Gear AVG-CS-HDMI44 4K HDMI 4X4 Matrix

The AVG-CS-HDMI44 is a 4K HDMI 4×4 Matrix, with 4 HDMI inputs and 4 HDMI outputs, supporting HDMI1.4 and HDCP2.2,it offers high performance and great stability at a very low price point.

Features

  • Supports HDMI resolutions up to 4K@60Hz 4:2:0, including 1080p 3D video.
  • Fully compliant with the HDMI 1.4 and HDCP 2.2 specifications.
  • Smart EDID management to match the connected displays.
  • Supports front panel buttons, IR remote and RS232 control.

Specifications

Video Input
Input (4) HDMI
Input Connector (4) female type A HDMI
HDMI Version 1.4
HDCP Version 2.2
Video Output
Output (4) HDMI
Output Connector (4) female type A HDMI
HDMI Version 1.4
HDCP Version 1.4
General
Maximum Video Resolution 4K@60Hz 4:2:0
Maximum Bandwidth 10.2 Gbps
Control Options Front Panel, IR Remote, RS232
Input Power 12V DC 2A
AC Adapter Input Power 100 ~ 240 V AC, 50/60 Hz
Maximum Power Consumption 10 watts
Operation Temperature 0 ~ +40℃
Storage Temperature -10 ~ +55℃
Relative Humidity 10% ~ 90%
Dimension (W*H*D)

244mm x 25.5mm x 100mm;

269mm x 25.5mm x 100mm (with Mounting Ears)
Net Weight 650g
