Denon PMA-1700NE Integrated Amplifier
Featuring advanced ultra-high current single push-pull circuit power, Advanced AL32 Processing Plus, and MM/MC phono equalizer, the Denon PMA-1700NE integrated amplifier delivers extraordinary sound quality with precise detail.
High-power 140W integrated amplifier
Drive your loudspeakers with 140 Watts of power per-channel into 4 Ohms. This integrated amplifier offers compatibility with the widest range of speaker types and impedances for operational stability.
Advanced AL32 Processing Plus
Advanced AL32 Processing Plus supports digital audio sources up to high resolution of 384-kHz/32-bit. The algorithms restore information that was lost during the digital recording to ensure detailed playback.
USB-DAC
PMA-1700NE provides USB-DAC function that supports high resolution audio signals up to 11.2-MHz DSD and 384-kHz/32-bit PCM. These digital signals with suppressed jitter will get passed on to the high quality DAC for an optimal D/A conversion with highest precision.
High-precision electrical controls
The PMA-1700NE embraces electrical volume, balance, and tone controls while preserving the analogue feeling of operation. The unique mechanism offers smooth, linear control. A Source Direct function passes by all tone control for purest audio.
Features
- High-power 140W integrated amplifier
- Advanced AL32 Processing Plus
- USB-DAC supporting 11.2- MHz DSD and 384-kHz/32-bit PCM
- MM and MC phono equalizer
- High-precision electrical controls
- Optical and coaxial digital inputs
- External pre-amp input terminals
- Six-block chassis configuration and direct mechanical ground construction
- Build integrity with thoughtfully selected components
Specifications
Rated Output Power | 70W + 70W (8ohm,20Hz-20kHz,THD0.07%) 140W + 140W (4ohm, 1kHz, THD0.7%) |
Speaker Impedance | A or B : 4 ~ 16ohm A + B : 8 ~ 16ohm |
Frequency Response | 5Hz - 100kHz (0~ -3dB) |
Total Harmonic Distortion | 0.01 % (Rated output: –3 dB), 8 ohm/ohms, 1 kHz |
Dumping Factor | 100 and over |
Input Sensitivity: Phono input | MM: 2.5 mV / 47 kohm MC: 200 |
RIAA Deviation | 20 Hz - 20 kHz ±0.5 dB (MM/MC) |
Phono Maximum Input | MM : 130mV / 1kHz MC : 10mV / 1kHz |
Input Sensitivity: CD/LINE/RECORDER | 125 mV / 19 kohm |
Input Sensitivity: Power Amp input | 0.85V / 47kohm (EXT. PRE) |
Signal to Noise Ratio | PHONO (MM): (89dB) PHONO (MC): (74dB) CD: (107dB) |
Tone Control | BASS : 100Hz ±8dB TREBLE : 10kHz ±8dB |
Power Consumption | 295W |
at Standby | 0.2W TV autoplay off 0.4W TV autoplay on |
