The Yamaha SR-B40A Soundbar is a high-quality audio device that enhances the sound of your TV or music. It is easy to set up and use, providing a great listening experience.
B40A - Soundbar with Dolby Atmos®. External subwoofer.
| SR-B40A | |||
|---|---|---|---|
| General | Drivers | Centre unit: Front L/R: 4.6 cm (1.8“) cone × 4, Tweeter: 2.5 cm (1") dome × 2, Subwoofer: 16 cm (6-1/4") cone ×1 | |
| Output Power | 200 W (Front L/R: 50 W × 2-ch, Subwoofer: 100 W) | ||
| Power Consumption | Centre unit: 25 W, Subwoofer: 20 W | ||
| Standby Power Consumption | Centre unit: 0.3 W (HDMI control off, Bluetooth standby off), 0.6 W (HDMI control on, Bluetooth standby on) Subwoofer: 0.8 W | ||
| Dimensions (W x H x D) | Centre unit: 910 × 68 × 133 mm (35-7/8” × 2-5/8” × 5-1/4”), Subwoofer: 194 × 419 × 407 mm (7-5/8” × 16-1/2” × 16”) | ||
| Weight | Centre unit: 2.9 kg (6.4lbs), Subwoofer: 8.1 kg (17.9lbs) | ||
| Input / Output | HDMI | 1 out (eARC) | |
| Digital Optical | Yes | ||
| Subwoofer output | No | ||
| Analog Audio | No | ||
| HDMI | 4K Pass-through | No | |
| eARC/ARC | eARC/ARC | ||
| CEC | Yes | ||
| Auto Lip-Sync | No | ||
| Sound Technology | Surround Technology | Dolby Atmos | |
| Surround Mode | Stereo, Standard, Movie, Game | ||
| Compressed Music Enhancer | No | ||
| Bass Extension | Yes | ||
| Audio Formats | Dolby Digital | Yes | |
| Dolby Pro Logic II | No | ||
| DTS Digital Surround | No | ||
| File Format | - | ||
| Connectivity | Wireless Music Streaming | No | |
| Wi-Fi | No | ||
| MusicCast Surround | No | ||
| AirPlay | No | ||
| Bluetooth Version/Profile | Version: Ver 5.1 / Profiles: A2DP / Codecs: SBC, AAC | ||
| Bluetooth Maximum Communication Range | Approx. 10 m ; 33ft (without obstructions) | ||
| Wireless Subwoofer | Yes | ||
| Other Features | App Control | Yes (Sound Bar Remote) | |
| Learning Function | No | ||
